Double Eccentric Butterfly Valves

Wafer, Lugged

Type: Butterfly Valves

Size: 2" (50nb) - 48" (1200nb)

Rating: ANSI 150, 300 & 600lb on request

Body: Hastelloy (C276), Duplex, Super Duplex, Titanium, Titanium Alloy, Nickel Alloys, Monel, Alu-Bronze, Stainless

Alloys and Austenitic Stainless Steel.

Design: API609, ASME B16.5, ASME B16.47 Series A, ASME B16.34

Seats: PTFE, RPTFE (15% Glass), RPTFE (25% Carbon), Viton & other materials available on request.

Flange Drilling Options: ANSI 150lb, 300lb, Wafer & Lugged

Face to Face: API 609

Features: Anti-static, Blowout Proof Stem, API 607 Firesafe Available, In line Adjustable Packing, Uni or Bi-Directional for soft seat, Zero Leakage

Actuation Options: Lockable Lever, Gearbox Operated, Lockable Gearbox Operated, Pneumatic Actuated (SR or DA), Electric Actuated, Position Control.

Actuator Mount: ISO 5211

Testing: API 598
